Portable diagnostic imaging

Mobile DI is the first and only mini C-arm designed specifically for your clinical and off-site imaging needs.

Combine portability and ease of movement with industry-leading digital X-ray and fluoroscopy. Introduce additional procedures with established CPT codes for increased reimbursement.

Improve your workflow and your patients’ satisfaction with Orthoscan Mobile DI.

Built to go where you go

Uniquely designed for those on the move, Mobile DI is a 35lb self-contained mini C-arm. Easily move between satellite clinics and off-site locations with the optional wheeled storage case.

Get high quality digital X-ray and fluoroscopy where you need it with Mobile DI.

35lb
SELF-CONTAINED UNIT
Anatomy revealed

  • See more on-screen content with a resolution of 1920 x 1200 in bright detail on a hi-bright 24″ monitor for an immersive work experience.

    The advanced Orthotouch touchscreen user interface allows seamless operation of system controls while still allowing for keyboard functions.

    Expect exceptional diagnostic imagery with a 12″ x 9.5″ live image to see fine details of anatomy with vivid clarity.

  • 24″

    DIAGNOSTIC MONITOR

  • Orthotouch 2.0

    TOUCHSCREEN INTERFACE

  • 12″ x 9.5″

    LIVE IMAGE

Effortless movement
and optimal viewing

  • 1. MOBILE ACCESSORY CART | Transport your Mobile DI easily between exam rooms and clinics with the optional accessory cart.
  • 2. MONITOR ARM | With improved monitor arm articulation, view real-time results with your patients on a detail-rich display.
  • 3. IMAGING FLEXIBILITY | Whether standing or sitting, reposition the detector to achieve optimal positioning of anatomy.
Additional procedures
Discover the possibilities of an improved workflow, increased patient satisfaction, and reduced lead times with these additional procedures.
  • Dynamic views
  • Fluoroscopic guided injections
  • Radiologic examinations
  • Stress views
  • Pin removals
  • Closed reductions
  • Motion studies
  • Joint stability tests
  • Arthrography
Specifications
US
Metric
  • Mechanical
    • Free space
      13.8″
      35cm
    • Mobile DI weight
      35lb
      15.9kg
    • Mobile DI height
      25″
      63.5cm
    • Mobile DI footprint (W x L)
      12″ x 19″
      30.5cm x 48.3cm
    • Accessory cart weight
      155lb
      70.3kg
    • Accessory cart height
      57.5″
      146.1cm
    • Accessory cart footprint (W x L)
      24″ x 27″
      61cm x 68.6cm
    • Arc depth
      8.5″
      21.6cm
    • Pivot rotation
      430°
      430°
    • Weight bearing foot bench
      Optional
      Optional
    • Keyboard handles
      ✓
      ✓
  • Detector
    • Type
      CMOS detector
      CMOS detector
    • Detector resolution
      2 k x 1.5 k
      2 k x 1.5 k
    • Detector size
      15cm x 12cm
      15cm x 12cm
    • Useful array
      14.5cm x 11.5cm
      14.5cm x 11.5cm
    • Pixel spacing
      75 microns
      75 microns
    • Dose rate
      AKR / DAP
      AKR / DAP
  • Monitor
    • Display size
      24″ LCD
      24″ LCD
    • Primary “live” image
      12″ x 9.5″
      30.5cm x 24.1cm
    • Dual reference image
      5″ x 4″
      12.7cm x 10.2cm
    • Brightness
      575 cd/m2
      575 cd/m2
    • Resolution
      1920 x 1200
      1920 x 1200
    • Interface
      DVI
      DVI
    • Arm horizontal reach
      27″
      68.6cm
    • Arm lateral rotation
      360° + 270° + 160°
      360° + 270° + 160°
    • Touchscreen
      ✓
      ✓
    • HDMI (external monitor)
      ✓
      ✓
    • Built-in DICOM calibration
      ✓
      ✓
  • Electrical
    • Input power
      100-230 VAC @ 50-60 Hz
      100-230 VAC @ 50-60 Hz
    • Field controls
      Single
      Single
    • Wired hand & foot switch
      ✓
      ✓
    • Laser alignment
      ✓
      ✓
    • USB 2.0 port
      ✓
      ✓
    • EMI filter
      ✓
      ✓
  • X-RAY GENERATOR
    • Focal spot
      42.5 microns
      42.5 microns
    • kV range
      40 – 78 kVp
      40 – 78 kVp
    • mA range
      0.040 – 0.160 mA
      0.040 – 0.160 mA
    • Operating mode
      Continuous
      Continuous
  • Documentation
    • Wireless communication
      Capable
      Capable
    • Image capacity
      26,000
      26,000
    • Video capacity
      14.4min
      14.4min
    • Cine loop frame rate
      30 fps
      30 fps
    • Adaptive noise suppression
      Automatic
      Automatic
    • Manual noise suppression
      4 modes
      4 modes
    • MPPS
      ✓
      ✓
    • Cine loop export
      ✓
      ✓
    • Snapshot capabilities
      ✓
      ✓
    • EMR connectivity
      ✓
      ✓
    • Edge enhancement
      ✓
      ✓
    • Post process brightness / contrast
      ✓
      ✓
    • DICOM 3.0 compliant
      ✓
      ✓
  • Brakes & Wheels
    • Braking system
      Lock & release
      Lock & release
    • Ground clearance
      3.5″
      8.9cm
  • Performance
    • Start-up time
      60 sec
      60 sec
  • Software
    • Software
      Orthotouch™
      Orthotouch™
    • Operating system
      Windows 10
      Windows 10
Satisfied customers
  • We have one of the Mobile DI units and actually designed our clinic around it.
    Jonathan Isaacs, M.D.
    M.D. Associate Professor & Chair, Division of Hand Surgery
  • The quality of the live fluoroscopy, it’s much better than what I have in the operating room.
    Jon Donigan, M.D.
    Orthopedic Hand Surgeon
  • The best X-ray equipment you can get if you’re an extremity surgeon.
    Dr. Michael Fitzmaurice
    Minimally Invasive Hand & Nerve Surgeon
Not paid testimonials
Reimbursement calculator
Discover your potential revenue from using an Orthoscan mini C-arm. Simply enter your estimated monthly usage and lease amount below to begin.
  • CPT CODE
  • DESCRIPTION
  • MEDICARE NTL AVG
  • PER MONTH
    • 76000
    • Fluoroscopy, up to one hour
    • $46
    • 77002
    • Fluoroscopic needle guidance
    • $100
    • 77071
    • Stress view
    • $50
    • 73030
    • Shoulder, radiologic examination
    • $29
    • 73110
    • Wrist, radiologic examination
    • $36
    • 73564
    • Knee, radiologic examination
    • $41
    • 73630
    • Foot, radiologic examination
    • $30
    • 73580
    • Knee, radiologic exam, arthrography
    • $125
Estimated lease amount
$
Potential monthly reimbursement
0
$
Estimated monthly lease payment
0
$
Potential monthly revenue
0
$
* Reimbursement amounts are rounded 2019 Medicare national averages and do not represent actual reimbursement in your area. CPT © 2019 American Medical Association. CPT is a registered trademark of the American Medical Association.
Ready for the next step?
Request a quote
PRODUCT BROCHURES
  • Mobile DI Spec Sheet – US (0.5 MB)
  • Mobile DI Brochure – US (1.8 MB)
